Discussion 10: Interpreters

Attendance

Your TA will come around during discussion to check you in. You can start on the worksheet before being checked in; you don't need to wait for your TA to get started.

If you didn't attend for a good reason (such as being sick), fill out this form (within 2 weeks of your discussion): attendance form

Representing Lists

A Scheme call expression is a Scheme list that is represented using a Link instance in Python.

For example, the call expression (+ (* 3 4) 5) is represented as:

Link('+', Link(Link('*', Link(3, Link(4, nil))), Link(5, nil)))

Those nil's are optional because nil is Link.empty, which is the default second argument to the __init__ method of the Link class.

Link('+', Link(Link('*', Link(3, Link(4))), Link(5)))

(+ (* 3 4) 5)

The Link class and nil object are defined in link.py of the Scheme project.

class Link:
    "A Scheme list is a Link in which rest is a Link or nil."
    empty = ()
    def __init__(self, first, rest=empty):
        self.first = first
        self.rest = rest

    ... # There are also __str__, __repr__, and map methods, omitted here.

nil = Link.empty

Q1: Representing Expressions

Write the Scheme expression in Scheme syntax represented by each Link below.

>>> Link('+', Link(1, Link(Link('*', Link(2, Link(3, nil))), nil)))

>>> Link('and', Link(Link('<', Link(1, Link(0, nil))), Link(Link('/', Link(1, Link(0, nil))), nil)))

Evaluation

Q2: Evaluation

(Note: Some past exams have had a question in exactly this format.) Which of the following are evaluated when scheme_eval is called on (if (< x 0) (- x) (if (= x -2) 100 y)) in an environment in which x is bound to -2? (Assume <, -, and = have their default values.)

  • if
  • <
  • =
  • x
  • y
  • 0
  • -2
  • 100
  • -
  • (
  • )

To evaluate the expression (+ (* 3 4) 5) using the Project 4 interpreter, scheme_eval is called on the following expressions (in this order):

  1. (+ (* 3 4) 5)
  2. +
  3. (* 3 4)
  4. *
  5. 3
  6. 4
  7. 5

The * is evaluated because it is the operator sub-expression of (* 3 4), which is an operand sub-expression of (+ (* 3 4) 5).

An if expression is also a Scheme list represented using a Link instance.

For example, (if (< x 0) (- x) x) is represented as:

Link('if', Link(Link('<', Link('x', Link(0, nil))), Link(Link('-', Link('x', nil)), Link('x', nil))))

To evaluate this expression in an environment in which x is bound to 2 (and < and - have their default values), scheme_eval is called on the following expressions (in this order):

  1. (if (< x 0) (- x) x)
  2. (< x 0)
  3. <
  4. x
  5. 0
  6. x

Q3: Print Evaluated Expressions

Define print_evals, which takes a Scheme expression expr that contains only numbers, +, *, and parentheses. It prints all of the expressions that are evaluated during the evaluation of expr. They are printed in the order that they are passed to scheme_eval.

Note: Calling print on a Link instance will print the Scheme expression it represents.

>>> print(Link('+', Link(Link('*', Link(3, Link(4, nil))), Link(5, nil))))
(+ (* 3 4) 5)

More Scheme!

Q4: Slice It!

Implement the get-slicer procedure, which takes integers a and b and returns an a-b slicing function. An a-b slicing function takes in a list as input and outputs a new list with the values of the original list from index a (inclusive) to index b (exclusive).

Your implementation should behave like Python slicing, but should assume a step size of one with no negative slicing indices. Indices start at zero.

Note: the skeleton code is just a suggestion. Feel free to use your own structure if you prefer.

Q5: Reverse

Write the procedure reverse, which takes in a list lst and outputs a reversed list.

Hint: you may find the built-in append procedure useful.
