Discussion 10: Interpreters

disc10.pdf

Attendance

Your TA will come around during discussion to check you in. You can start on the worksheet before being checked in; you don't need to wait for your TA to get started.

If you didn't attend for a good reason (such as being sick), fill out this form (within 2 weeks of your discussion): attendance form

Representing Lists

A Scheme call expression is a Scheme list that is represented using a Link instance in Python.

For example, the call expression (+ (* 3 4) 5) is represented as:

Link('+', Link(Link('*', Link(3, Link(4, nil))), Link(5, nil)))

Those nil's are optional because nil is Link.empty, which is the default second argument to the __init__ method of the Link class.

Link('+', Link(Link('*', Link(3, Link(4))), Link(5)))

(+ (* 3 4) 5)

The Link class and nil object are defined in link.py of the Scheme project.

class Link:
    "A Scheme list is a Link in which rest is a Link or nil."
    empty = ()
    def __init__(self, first, rest=empty):
        self.first = first
        self.rest = rest

    ... # There are also __str__, __repr__, and map methods, omitted here.

nil = Link.empty

Q1: Representing Expressions

Write the Scheme expression in Scheme syntax represented by each Link below.

>>> Link('+', Link(1, Link(Link('*', Link(2, Link(3, nil))), nil)))

>>> Link('and', Link(Link('<', Link(1, Link(0, nil))), Link(Link('/', Link(1, Link(0, nil))), nil)))

Answer 1: (+ 1 (* 2 3))

Answer 2: (and (< 1 0) (/ 1 0))

Evaluation

Q2: Evaluation

(Note: Some past exams have had a question in exactly this format.) Which of the following are evaluated when scheme_eval is called on (if (< x 0) (- x) (if (= x -2) 100 y)) in an environment in which x is bound to -2? (Assume <, -, and = have their default values.)

if
<
=
x
y
0
-2
100
-
(
)

To evaluate the expression (+ (* 3 4) 5) using the Project 4 interpreter, scheme_eval is called on the following expressions (in this order):

(+ (* 3 4) 5)
+
(* 3 4)
*
3
4
5

The * is evaluated because it is the operator sub-expression of (* 3 4), which is an operand sub-expression of (+ (* 3 4) 5).

An if expression is also a Scheme list represented using a Link instance.

For example, (if (< x 0) (- x) x) is represented as:

Link('if', Link(Link('<', Link('x', Link(0, nil))), Link(Link('-', Link('x', nil)), Link('x', nil))))

To evaluate this expression in an environment in which x is bound to 2 (and < and - have their default values), scheme_eval is called on the following expressions (in this order):

(if (< x 0) (- x) x)
(< x 0)
<
x
0
x

The symbol if is not evaluated because it is the start of a special form, not part of a call expression. The symbols that introduce special forms (and, if, lambda, etc.) are never evaluated.

The symbol - is not evaluated, nor is the whole sub-expression (- x) that it appears in, because (< x 0) evaluates to #f. If you're still not certain why some parts are evaluated and some aren't, ask the course staff.

Q3: Print Evaluated Expressions

Define print_evals, which takes a Scheme expression expr that contains only numbers, +, *, and parentheses. It prints all of the expressions that are evaluated during the evaluation of expr. They are printed in the order that they are passed to scheme_eval.

Note: Calling print on a Link instance will print the Scheme expression it represents.

>>> print(Link('+', Link(Link('*', Link(3, Link(4, nil))), Link(5, nil))))
(+ (* 3 4) 5)

Your Answer

Solution

    def print_evals(expr):
        """Print the expressions that are evaluated while evaluating expr.

        expr: a Scheme expression containing only (, ), +, *, and numbers.

        >>> nested_expr = Link('+', Link(Link('*', Link(3, Link(4, nil))), Link(5, nil)))
        >>> print_evals(nested_expr)
        (+ (* 3 4) 5)
        +
        (* 3 4)
        *
        3
        4
        5
        >>> print_evals(Link('*', Link(6, Link(7, Link(nested_expr, Link(8, nil))))))
        (* 6 7 (+ (* 3 4) 5) 8)
        *
        6
        7
        (+ (* 3 4) 5)
        +
        (* 3 4)
        *
        3
        4
        5
        8
        """
        if not isinstance(expr, Link):
            print(expr)
        else:
            print(expr)
            while expr is not nil:
                print_evals(expr.first)
                expr = expr.rest

More Scheme!

Q4: Slice It!

Implement the get-slicer procedure, which takes integers a and b and returns an a-b slicing function. An a-b slicing function takes in a list as input and outputs a new list with the values of the original list from index a (inclusive) to index b (exclusive).

Your implementation should behave like Python slicing, but should assume a step size of one with no negative slicing indices. Indices start at zero.

Note: the skeleton code is just a suggestion. Feel free to use your own structure if you prefer.

Your Answer

Solution

(define (get-slicer a b)
  (define (slicer lst)
    (define (slicer-helper c i j)
      (cond
        ((or (null? c) (<= j i)) nil)
        ((= i 0) (cons (car c) (slicer-helper (cdr c) i (- j 1))))
        (else (slicer-helper (cdr c) (- i 1) (- j 1)))))
    (slicer-helper lst a b))
  slicer)

; DOCTESTS (No need to modify)
(define a '(0 1 2 3 4 5 6))
(define one-two-three (get-slicer 1 4))
(define one-end (get-slicer 1 10))
(define zero (get-slicer 0 1))
(define empty (get-slicer 4 4))

(expect (one-two-three a) (1 2 3))
(expect (one-end a) (1 2 3 4 5 6))
(expect (zero a) (0))
(expect (empty a) ())

Q5: Reverse

Write the procedure reverse, which takes in a list lst and outputs a reversed list.

Hint: you may find the built-in append procedure useful.

Your Answer

Solution

(define (reverse lst)
    (if (null? lst)
        nil
        (append
            (reverse (cdr lst))
            (list (car lst))))
)
